Model | Size (mm) | Bags (Pcs) | CMH | I.N.P (Pa) | F.N.P (Pa) | Filter object (μm) | EFF. (%) | Filtration Class | Color |
RT-DSHC7760-8P04 | 592*592*600 | 8 | 2200/3400 | <65/110 | <480 | ≥5 | 95% | G4 | white |
RT-DSHC7760-6P04 | 592*592*600 | 6 | 2200/3400 | <70/120 | <480 | ≥5 | 95% | G4 | white |
RT-DSHC5760-5P04 | 492*592*600 | 5 | 2000/3000 | <70/120 | <480 | ≥5 | 95% | G4 | white |
RT-DSHC1760-3P04 | 287*592*600 | 3 | 1000/1500 | <70/120 | <480 | ≥5 | 95% | G4 | white |
RT-DSHC7760-8P05 | 592*592*600 | 8 | 2200/3400 | <30/40 | <480 | ≥1 | 45% | F5 | white |
RT-DSHC7760-6P05 | 592*592*600 | 6 | 2200/3400 | <35/45 | <480 | ≥1 | 45% | F5 | white |
RT-DSHC5760-5P05 | 492*592*600 | 5 | 2000/3000 | <35/45 | <480 | ≥1 | 45% | F5 | white |
RT-DSHC1760-3P05 | 287*592*600 | 3 | 1000/1500 | <35/45 | <480 | ≥1 | 45% | F5 | white |
RT-DSHC7760-8P06 | 592*592*600 | 8 | 2200/3400 | <40/60 | <480 | ≥1 | 65% | F6 | white |
RT-DSHC7760-6P06 | 592*592*600 | 6 | 2200/3400 | <50/65 | <480 | ≥1 | 65% | F6 | white |
RT-DSHC5760-5P06 | 492*592*600 | 5 | 2000/3000 | <50/65 | <480 | ≥1 | 65% | F6 | white |
RT-DSHC1760-3P06 | 287*592*600 | 3 | 1000/1500 | <50/65 | <480 | ≥1 | 65% | F6 | white |
RT-DSHC7760-8P07 | 592*592*600 | 8 | 2200/3400 | <55/80 | <480 | ≥1 | 85% | F7 | white |
RT-DSHC7760-6P07 | 592*592*600 | 6 | 2200/3400 | <60/85 | <480 | ≥1 | 85% | F7 | white |
RT-DSHC5760-5P07 | 492*592*600 | 5 | 2000/3000 | <60/85 | <480 | ≥1 | 85% | F7 | white |
RT-DSHC1760-3P07 | 287*592*600 | 3 | 1000/1500 | <60/85 | <480 | ≥1 | 85% | F7 | white |
Note: Other specifications can be customized according to demand. | |||||||||
